| Key Features | ||
| Capacity | 128GB | |
| Form Factor | M.2 2280 | |
| Flash Type | 3D NAND | |
| Interface | PCIe Gen3x4, NVMe 1.3 | |
| Sequential R/W | 1800/560 MB/s | |
| MTBF | Up to 1,500,000 Hours | |
| TBW | 75 | |
| Others | Phison E13T Controller 4K Random Read/Write up to 215,000/330,000 IOPS TERABYTES WRITTEN (TBW): 800 TRIM (Performance Optimization, OS support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low-Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) AES256/TCG OPAL2.0/Pyrite (Encryption, Data Security) | |
| Physical Specification | ||
| Dimension | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) | |
| Temperature | ||
| Operating Temperature | 0°C – 70°C | |
| Storage Temperature | -40°C – 85°C | |
| Warranty | ||
| Manufacturing Warranty | 5 Years | |
